5.8G 16dbi patch directional antenna

5.8G 16dbi patch directional antenna for 5.8G video receiver or DVR

parameters

Frequency Range: 5725 - 5900 MHz

Bandwidth: 125MHz

Gain: 16dBi

Vertical Beamwidth: 16 degrees

Horizontal Beamwidth: 14 degrees

VSWR: <1.5

Polarization: vertical or horizontal

Impedance: 50 ohms

Maximum Power: 100W

Connector: N to RPSMA

Size: 20x18cm
Weight: 250g
N to RPSMA wire length : 2m

The following pic shows how the antenna is connected with 5.8G 8CH receiver

the receiver is not included in this product.
