Cyclops Storm OSD best value AHRS based OSD with RTL/RTH fucntion:
Cyclops released another breakthrough product Storm OSD, no need other staberlizer module, no need doctor degree to use the OSD, what's more, as always, high performance with amazing reasonable price.
♦ Reliable AHRS based, don't be affected by weather and background of flying field. Fully tested with wooden, EPO, EPP and even oil-drived 15-class planes, proven robust anti-vibration algorithms. No need extra anti-vibration devices.
♦ Tiny size with ALL-IN-ONE design, the main-board integrates OSD, Gyro sensor,accelerometer sensor， barometre sensor, and the control unit, also with enough input and output ports, offer precise attitute hold and staberlization.
♦ Fully tested with different kinds of planes, support normal 4-channels plane, V-tail, and flyingwings.
♦ 3 flying modes, make your fly easier and funny, manual mode, PA mode, and RTH mode
♦ 3 OSD screens, you can always find your favorite one
♦ New 10hz gps module with back-up battery, 5 seconds locking time after first locking. 100A current sensor module.
Your purchase includes:
1* Storm OSD main board
1* 100A current sensor module
1* GPS module
1* configuration button board
all related wire cable included
Firmware V1.04: (Improved RTH sensitivity, better 433mhz RC compatibility) Download
Firmware V1.1 Released: Download
Note: to update the firmware, USB link/ upgrader is necessary: http://www.foxtechfpv.com/stormnova-osd-usb-link-upgrader-p-514.html
All included, STORM OSD, key pad, 10hz gps, 100A current sensor.
We have add a new case for storm OSD in latest package.You can fix the case for best protection or choose naked OSD for lightest weight.
some of the early batch storm osd are equipped with incorrected configured GPS,if you had problem with GPS information, please check your GPS and modify the power supply method as per shown in the photo.
