WDR 750 600tvl wide dynamic range mini cam（PAL）

 Image Device

1/3” SONY Super HAD CCD II

 Scanning System

2 : 1 Interlace

 Scanning Freq.

 NTSC : 15.734 KHz(H), 59.94 Hz(V)

 PAL : 15.625 KHz(H), 50 Hz(V)

 Total Pixels

NTSC:811(H)x508(V) 410K, PAL:795(H)x596(V) 470K

 Effective Pixels

NTSC:768 (H)x494(V) 380K, PAL:752(H)x582(V) 440K

 Sync System

Internal

 H. Resolution

600 TV Lines

 Luminance S/N

More Than 50dB (AGC Off)

 Min. Illumination

0.1Lux

 Video Output Signal

1Vp-p Composite(75ohm)

 OSD Display

Available

 Lens

Pinhole Lens

 Shutter Speed

1/60 ~ 1/100,000(NTSC), 1/50 ~ 100,000(PAL)

 Gain Control

LOW / MIDDLE / HIGH

 Sens-up

Adjustable

 D-WDR

WDR IN / WDR OUT

 BLC

ON / OFF

 2D-DNR

0 ~ 100

 HLC

All Day / Night

 White Balance

ATW 1 / AWC->SET / Manual

 Sharpness

Adjustable

 Motion Detection

4 Zone

 Privacy Masking

8 Zone

 Digital Zoom

Available

 Power Consm.

 DC12V : DC12V(±10%)

 Dimension(mm)

30(W) x 30(H) x 23 (D)

 Weight

Approx. 30g
