Parameters:
Sensor: Single chip 1/3 CMOS
System: NTSC & PAL
Number of pixel: NTSC: L656 (H)x492 (V); PAL：786 (H)x576 (V)
Image signal process: Digital signal processing system
Sensor dimension: 4.75 (H)x3.55mm (V)
Horizontal resolution: 520TV Lines
Scanning system: 2:1 Interlace
Sensitivity: 0.008Lux/F1.2
Lens& View angle: 0.5mm F2.0 / 62 °
S/N Ratio: 48dB
Video out: 1.0V p-p/75ohm
Size (LxWxH): 24x18x15mm
System: NTSC & PAL
Number of pixel: NTSC: L656 (H)x492 (V); PAL：786 (H)x576 (V)
Image signal process: Digital signal processing system
Sensor dimension: 4.75 (H)x3.55mm (V)
Horizontal resolution: 520TV Lines
Scanning system: 2:1 Interlace
Sensitivity: 0.008Lux/F1.2
Lens& View angle: 0.5mm F2.0 / 62 °
S/N Ratio: 48dB
Video out: 1.0V p-p/75ohm
Size (LxWxH): 24x18x15mm
Weight: 8g
Working voltage: 3.6-24V
Lens: 3.6mm
if you remove the regulator board on its back ,it will work at 3.3-5V
