- Signal frequency: 20-500Hz
- Output PWM frequency: 18KHz
- Application: BL heli firmware
- Continuous current: 20A
- Instant current: 22A
- Battery: 2~4S
- Dimension: 23x12x4.5mm
- Weight: 5.8g
- Designed specially for multi-copters with fast throttle response
- Good compatibility with motors
- The signal is transfered by twisted pair cable, reducing the interference between wires.
- The maximum refresh frequency is up to 500Hz, making it compatible with all flight controllers.
- Using mini ultra-low resistance MOSFET and high current N MOS flashes
