The iCharger 306B 1000W 30A 6S Charger adopts advanced synchronous buck-boost DC/DC converter technology to reach high conversion efficiency.16M flash memory,intelligent fan,temperature sensor,unique Lipo battery expanding fucntion and internal resistance measurement are the highlights among its features.
1.High power, high current, high-performance power conversion circuit. The iCharger series uses advanced Synchronous buck-boost DC/DC converter technology with an output conversion efficiency that can reach over 90%. This not only saves power and reduces heat build up but also makes the charger more compact and conveniently mobile.
2.Input power with 4mm bullet connectors butt-welded alligator clips and wide input voltage ranges from 4.5V to 38V. The output power can be adjusted to align with the available input power, thus preventting input current overload and protecting the DC source.The iCharger series can be used with three types of Lithium batteries - LiPo, Lilo, LiFe - and has a fully integrated cell balancer.
3.The fan will start automatically according to the internal temperature and charge/discharge power, and protect the charger if overheated. When the internal temperature is over 55℃(131 oF), the output power is automatically reduced by 25%. If the temperature exceeds 60℃(140 oF) the charge cycle is stopped.
4.Convenient set of 10 battery profile memories that can be saved and loaded by number.
5.2x16 backlit LCD screen that provides rich information including active mode, current, voltage, total charge (mAh), charging time and temperature etc.
6.Various charging/discharging settings and cycles to meet a wide range of customer needs. For Lithium batteries: balance charging, normal charging, fast charging, storage, discharging, ext-discharging, charge/discharge cycling, and battery monitoring. For NiCd/NiMH batteries: charging-auto, charging-manual, discharging, charge/discharge cycling and forming charge. For Pb batteries: charging and discharging.
7.Up to 1000w unique regenerative discharge capability. Regenerative discharge takes most of the output battery‘s energy and puts it back into the input battery, which is not the same with the traditional methods of discharge to deplete that energy in the form of heat across a transistor. That is, when you discharge your LiPo for storage, you will be re-charging your Lead Acid input battery. The amount of current and voltage that your input battery can accept limit the total amount of power that you can achieve, or 1000W, whichever is lower.
8.Unique Lithium battery expanding discharge program. When you connect the external capacity resistance, you can use it as the maximum discharge power capacity—1200W (@40V/30A).
9.Unique Lithium battery Monitor program. When you use other equipment to charge or discharge a Lithium pack, you can use the iCharger to monitor the per-cell voltages, battery temperature and process time. If any individual cell appears over-charged or over-discharged or the pack is too hot or the process has gone on for too long, the iCharger will generate an alarm sound and the related information will blink.
10.Electric motor test mode can be used to run-in electric motors, test motor parameters and performance, check tolerances etc.
11.Foam-cut drive. In this mode, the charger acts as a convenient power supply for a hot wire foam cutter.
12.Battery interior resistance measurement. The iCharger can not only measure the internal resistance of the battery pack, and also can measure the per-cell internal resistance (only available for lithium battery).
13.Perfect protection. The iCharger has protection for reversed polarity (input or output), low input voltage, battery temperature, charging capacity and time overrun.
14.iCharger 306B has a 16Mbit flash storage, which can log offline charge and discharge data in 36 hours.
15.Support upgrading the hardware program by USB port. The iCharger also support the ―logview‖ software and can display, plot and analyze the charge and discharge data by it.
Input voltage range: 4.50 – 38.0VDC
Charge current range: 0.05 – 30.0A
Discharge current range: 0.05 – 30.0A
Maximum charge power capacity: 1000W @ input voltage 23V (500W @ input voltage 12V)
Maximum discharge power capacity: 80W
Maximum regenerative discharge power capacity: 1000W
Maximum extern discharge power capacity: 1200W @ 40V/30A
Current drain for balancing: <500mA
Balance accuracy: <10mV
Lithium (LiPo/LiIo/LiFe) battery cell count: 1 – 6 series (In non-balance mode, expand LiFe to 12s)
NiCd/NiMH battery cell count: 1 – 25 series
Pb battery cell count: 1 – 18 series (2 – 36V)
Log Files storage: 16Mbit (31 hours)
Battery setup memories: 10
Intelligent temperature control: Yes
PC Connect: USB port
Dimensions (L X W X D): 143X123X46mm 5.63"*4.84"*1.81"
The charger cannot work independently, you need to purchase the power supply additionally!
