1400Mhz low pass filter

SKU: 000439

Availability: In stock ( 13 )

Weight:20g

$14.99
  • Qty Price
  • 5 $14.69
  • 10 $14.24

Reward points Earn you 15 reward points.

Qty:

Product Description
1.2GHz Low Pass Filter attenuates RF noise which interferes 2.4Ghz RC receivers
Helps 1.2GHz Wireless Video Transmitter to prevent unwanted RF noises
12LPF 1.2G Low pass filters can reduce the interference to 2.4GHz receivers to prevent jitter servo issues. You may install it onto your receivers or transmitters, for filtering out unwanted RF noises.

Designed for 1200MHz -1390MHz wireless A/V transmitters. Low insertion loss, less than 0.7dB typical at 1300MHz.Passband DC - 1425MHz (<-1.5dB loss)Efficient monolithic LC multi-pole topography design.Second harmonic (> 2.4GHz) attenuation -35dB typical. SMA connectors (male / female).Inserts between transmitter and antenna. Characteristic impedance 50次.Handles RF power up to 8 watts.Small size, 1.45 x 0.31 x 0.25 inches (37 x 8 x 6.5 mm).
Designed for 1200MHz -1390MHz wireless A/V transmitters
Low insertion loss, less than 0.7dB typical at 1300MHz
Passband DC - 1425MHz (<-1.5dB loss)
Efficient monolithic LC multi-pole topography design
Second harmonic (> 2.4GHz) attenuation -35dB typical
SMA connectors (male / female)
Characteristic impedance 50 ohm
Handles RF power up to 8 watts
Small size, 1.45 x 0.31 x 0.25 inches (37 x 8 x 6.5 mm)
Lightweight, 5.45 grams
