FH230 TIR 30X Optical Zoom and Thermal Camera with 2-axis Gimbal-Free Shipping

SKU: 809073

Availability: In stock ( 8 )

Weight:5KG

$14,999.00

Reward points Earn you 14999 reward points.

Qty:

FH230 TIR is a 2-axis high precision gimbal with a 30X starlight zoom camera and an thermal camera. This gimbal can be mounted on VTOL airplanes or other UAVs for applications like inspection, surveillance, search and rescue.

FH230 TIR features high quality video sensor. FH230 TIR using SONY EV7520 camera featuring 1080P 60FPS full HD video streaming(with a HDMI encoder, which can transfer the SDI to HDMI output) and 30X zoom capability, which will enable you to see objects in detail over distance. With onboard object tracking module, FH230 TIR is able to track static or moving target easily.

FH230 TIR 2-axis gimbal can not only be controlled via PWM signal, but also serial command. Also gimbal status like Yaw, Pitch, zoom can be obtained by sending serial command to the gimbal via its serial port.

FH230 TIR 2-axis gimbal comes with one wiring hub for RC receiver and video output port, which makes wiring very easy and clean. Also the gimbal has 2 smart speed modes: FAST speed and LOW speed. Fast speed mode is used for small zooming range, which makes the gimbal control sensitive and quick; LOW speed mode is used for large zoom range, will enable you to target the object more accurately.

FH230 TIR supports Pic-in-Pic function, the two pictures could be switched mutually, and also could geo-tag the video streaming and photos.




Specification:

Imager Sensor: 1/2.8-type Exmor CMOS
Video Output:1080P/60fps HDMI(SDI to HDMI)
Focal Length: 30X optical focal zoom,4.3-129mm
Wide Dynamic: Up to 105dB
Auto focus: Less than 1s
Low illumination: Color: 0.01 Ix(F1.6, AGC on, 1/30s)
Aperture: Φ16.0
SD card: support Max 128G, class 10, FAT32 or exFAT format

Thermal Camera:

Pixels: 640x480
Pixel Size: 17μm
Emissivity Correction: Emissivity 0.01~1 adjustable
Image Enhancement: Automatically adjusts image brightness and contrast
Color Palette: Black hot, white hot, pseudo color
Warning Temperature -20℃~120℃

Gimbal system:

Input voltage: 3S-4S
Static current: 400mA(@16v)
Dynamic current: 500mA(@16V)
Working Temperature: -20℃ ~ +80 ℃
Range of control angle:
Pitch:±90° Yaw:±170°
Control Precision:
Pitch: ±0.01°Yaw: ±0.01°
Size:195x127x122mm
Weight: 1180g
Control interface: PWM and serial command

Tracking:

Data Refresh Rate: 25Hz
Output lag: <3ms
Tracking Velocity: ±32 pix/frame
Target Size: 16x16 pixels - 128x128 pixels


Features:

-2-aixs high stabilized gimbal system
-1/2.8-type Exmor CMOS
-30X optical zoom, 1080P/60 HDMI output for video downlink
-1080P/30 H.264 video recorded for on-board TF card
-Auto object tracking
-Geo tagging
-PWM control and serial command control
-Convenient wiring hub for RC receiver and video output

Your Purchase Includes:

1x FH230 TIR 30X Optical Zoom and Thermal Camera
1x FH230 TIR 2-Axis Gimbal
