Foxtech NAGA Quadcopter RTF Package

Important Notice!
Our company's unmanned aerial vehicle (UAV) products only support domestic transactions within China. If your company intends to export UAV products from China, it is necessary to comply with Chinese regulations. Furthermore, the products cannot be used for military, terrorist, or war purposes.

- NAGA Quadcopter is a small size aerial platform of unrivalled performance for mapping, surveillance and inspection. Featuring IP65 rating folding frame, and multiple failsafe, NAGA packs practical tools in a miniature airframe.

- Its compact folding airframe enables easy operation and flexible maneuvering.

- Forged from a combination of carbon fiber, PCB and CNC, NAGA is both light, 5.4kg including a battery and tough, allowing flight mission under a wide temperature range of -10℃-55℃.

- A set of built-in antenna shields from dust and moist.

- Self-locking propellers spare the need for tools to mount.

- Under circumstances when Naga is in low voltage status or loss of signal, Return to Launch failsafe will be automatically triggered to save the day.

- Plan the flight path that can be saved for future mission on either Herelink 5.5" inch touch screen or on MissionPlanner/PC after linking herelink with PC through WiFi / Bluetooth/USB, drone flying becomes programmable and as simple as anyone can master. Alternatively, Herelink also serves as a streaming media server that delivers video and data (WAN) among team members on their devices like an ipad, mobile phone or PC, allowing a simultaneous team participation in the mission.

Specification

Version: NAGA Quadcopter Battery-powered Version

Color: Black and White

Material: Carbon Fiber, CNC, PCB

Control Range: 20km

Diagonal Wheelbase: 815mm

Unfolded Dimensions: 670mm*650mm*200mm (excluding propellers/landing gears)

Folded Dimensions: 440mm*210mm*200mm(excluding propellers/landing gears)

Operating Weight: 5.4kg (including battery)

Battery Weight: 2.8kg

Max Take-off Weight: 8kg

Max Speed: 30m/s

Max Lifting Speed: 4m/s

Max Descent Speed: 3m/s

Max Angle of Pitch: 25°

Wind Resistance: 14m/s

Service Ceiling: 6000m

Propeller: 22*8 inch

Working Voltage: 50.4V

Working Temperature: -10℃-55℃

Carrying Case: 68cm*45cm*35cm

Your Purchase Includes

RTF Package

1x NAGA ARF Combo

1x Flight Controller with GPS

1x Herelink V1.1 2.4GHz Long Range HD Video Transmission System

1x 14S Li-ion Battery

2x (pair) 22 inch Carbon Fiber Propeller

1x K4 Battery Charger

1x Carrying Case
